Keller
Keller LEO5 Digital Pressure Transmitter
السعر عند الطلب
بدون دفع عبر الإنترنت · أضف بنودًا إلى قائمة طلب العرض
تنزيل ورقة المواصفات PDF
طلب العرض يحمل بنود قائمة المواد فقط. أرسل لعرض هندسي.
المعاملات الرئيسية
Accuracy
+/-0.05% FS at room temperature (BFSL, hysteresis, non-repeatability, zero/span)
Type
Keller LEO5 high-resolution digital manometer / digital pressure gauge with logger
Total Error Band
+/-0.1% FS (0 to 50 C)
Pressure Ranges
About -1...3 bar through 0...1000 bar (standard range table)
Peak Mode
Pressure peak detection at 5 kHz sampling (reduced resolution/accuracy)
Standard Rate
2 samples/s standard measuring rate
| المعامل | القيمة |
|---|---|
| Accuracy | +/-0.05% FS at room temperature (BFSL, hysteresis, non-repeatability, zero/span) |
| Type | Keller LEO5 high-resolution digital manometer / digital pressure gauge with logger |
| Total Error Band | +/-0.1% FS (0 to 50 C) |
| Pressure Ranges | About -1...3 bar through 0...1000 bar (standard range table) |
| Peak Mode | Pressure peak detection at 5 kHz sampling (reduced resolution/accuracy) |
| Standard Rate | 2 samples/s standard measuring rate |
| Data Logger | Cyclical logger >=56,000 measured values with timestamp; interval/event modes |
| Interface | USB (Keller protocol) via Mini USB-B; rechargeable Li-ion battery |
| Battery Life | Up to about 2000 hours continuous (standard); about 160 hours peak mode |
| Protection | IP66 stainless housing with safety glass front; capacitive touch keys |
| Wetted Parts | AISI 316L process connection and diaphragm; FKM seals; silicone oil fill |
| Document | Keller LEO5 high-resolution digital manometer datasheet (OEM LEO5 sheet) |
