Transmille
Transmille 1000 Series Multifunction Calibrator
السعر عند الطلب
بدون دفع عبر الإنترنت · أضف بنودًا إلى قائمة طلب العرض
تنزيل ورقة المواصفات PDF
طلب العرض يحمل بنود قائمة المواد فقط. أرسل لعرض هندسي.
المعاملات الرئيسية
Accuracy class
1-year total accuracy specs at TCal +/-5 C (function-dependent tables)
Type
Portable / benchtop multifunction calibrator family (1000A rugged case / 1000B bench)
Functions
DC/AC voltage and current, resistance, capacitance, frequency, thermocouple
Dc Voltage
Ranges from 0-104 mV to 104-1020 V class; 1 uV to 10 mV resolution
Interfaces
USB standard
Power
110 V or 230 V line, 50-60 Hz; about 28 W standby / 200 W max
| المعامل | القيمة |
|---|---|
| Accuracy class | 1-year total accuracy specs at TCal +/-5 C (function-dependent tables) |
| Type | Portable / benchtop multifunction calibrator family (1000A rugged case / 1000B bench) |
| Functions | DC/AC voltage and current, resistance, capacitance, frequency, thermocouple |
| Dc Voltage | Ranges from 0-104 mV to 104-1020 V class; 1 uV to 10 mV resolution |
| Interfaces | USB standard |
| Power | 110 V or 230 V line, 50-60 Hz; about 28 W standby / 200 W max |
| Environment | Operation 0 to +50 C; storage -5 to +60 C; RH class <80% to 30 C |
| Models | 1000A ultra-portable ruggedised case; 1000B compact bench (cream RAL9002) |
| Document | Transmille 1000 Series Extended Specifications V1.03 (Feb 2014) |
