Mensor (WIKA)
Mensor CPG2400 Digital Pressure Gauge
السعر عند الطلب
بدون دفع عبر الإنترنت · أضف بنودًا إلى قائمة طلب العرض
تنزيل ورقة المواصفات PDF
طلب العرض يحمل بنود قائمة المواد فقط. أرسل لعرض هندسي.
المعاملات الرئيسية
Accuracy
0.03% FS
Display
LCD with peak and null functions
Instrument Type
Single-range desktop digital pressure gauge / barometer
Pressure Ranges
10 inH2O to 6,015 psi; absolute, gauge, bidirectional or vacuum
Temperature Compensation
15 to 45 °C without accuracy degradation
Communications
RS-232 or RS-485 serial
| المعامل | القيمة |
|---|---|
| Accuracy | 0.03% FS |
| Display | LCD with peak and null functions |
| Instrument Type | Single-range desktop digital pressure gauge / barometer |
| Pressure Ranges | 10 inH2O to 6,015 psi; absolute, gauge, bidirectional or vacuum |
| Temperature Compensation | 15 to 45 °C without accuracy degradation |
| Communications | RS-232 or RS-485 serial |
| Pressure Units | 17 selectable + 1 user-defined |
| Applications | Desktop monitoring, production/test benches, mercury manometer replacement |
| Datasheet | WIKA CPG2400 |
| Warranty | Two year warranty (OEM) |
| Form Factor | Compact single-range package |
| Remote | Serial configure/read/calibrate |
