Testo
Testo 316-3 Electronic Refrigerant Leak Detector
السعر عند الطلب
بدون دفع عبر الإنترنت · أضف بنودًا إلى قائمة طلب العرض
تنزيل ورقة المواصفات PDF
طلب العرض يحمل بنود قائمة المواد فقط. أرسل لعرض هندسي.
المعاملات الرئيسية
Sensor type
Heated diode / replaceable sensor head
Sensitivity
4 g/a (0.15 oz/a)
Detectable Refrigerants
R-22, R134a, R-404A, R-410A, R-507, R438A and all CFCs, HFCs, HCFCs
Conformities
SAE J1627, EN 14624:2012, EG 2004/108/EG
Sensor Lifetime
Approx. 80–100 h (≈1 year typical)
Operating Temperature
−18 to +50 °C
| المعامل | القيمة |
|---|---|
| Sensor type | Heated diode / replaceable sensor head |
| Sensitivity | 4 g/a (0.15 oz/a) |
| Detectable Refrigerants | R-22, R134a, R-404A, R-410A, R-507, R438A and all CFCs, HFCs, HCFCs |
| Conformities | SAE J1627, EN 14624:2012, EG 2004/108/EG |
| Sensor Lifetime | Approx. 80–100 h (≈1 year typical) |
| Operating Temperature | −18 to +50 °C |
| Operating Humidity | 20 to 80 %RH |
| Storage Temperature | 0 to +50 °C |
| Battery | 2× D cells; 16 h continuous operation |
| Weight | Approx. 500 g including batteries |
| Indication | LED leakage indicator with simultaneous audible alarm |
| Zeroing | Automatic zeroing; ready immediately after power-on |
| Order Number | 0563 3163 |
| Measuring Parameter | g/a leak rate |
