Transmille
Transmille 3050A Multi-Product Calibrator
السعر عند الطلب
بدون دفع عبر الإنترنت · أضف بنودًا إلى قائمة طلب العرض
تنزيل ورقة المواصفات PDF
طلب العرض يحمل بنود قائمة المواد فقط. أرسل لعرض هندسي.
المعاملات الرئيسية
Type
Precision multi-product calibrator (Transmille 3050A / 3000A Series)
Dc Voltage
0–202 mV to 200–1025 V ranges (extended specifications V1.60)
Functions
DC/AC voltage, DC/AC current, resistance, capacitance, frequency, thermocouple simulation
Line Power
Selectable 110 V / 230 V; variation −6% / +10%
Connections
4 mm safety sockets for voltage/2-wire resistance and low-current ≤2 A
Dc Voltage Accuracy
1-year total accuracy class ~50 ppm of setting + offset (range-dependent)
| المعامل | القيمة |
|---|---|
| Type | Precision multi-product calibrator (Transmille 3050A / 3000A Series) |
| Dc Voltage | 0–202 mV to 200–1025 V ranges (extended specifications V1.60) |
| Functions | DC/AC voltage, DC/AC current, resistance, capacitance, frequency, thermocouple simulation |
| Line Power | Selectable 110 V / 230 V; variation −6% / +10% |
| Connections | 4 mm safety sockets for voltage/2-wire resistance and low-current ≤2 A |
| Dc Voltage Accuracy | 1-year total accuracy class ~50 ppm of setting + offset (range-dependent) |
| High Voltage Safety | Auto standby above 20 V / 200 V steps; ramped HV for auto-ranging DUTs |
| Platform | 3000A Series workstation calibrator with optional lead sets and scopes amplitude verification |
| Document | 3050A Extended Specifications V1.60 + 3000 Series Operation Manual V5.10 |
| Applications | Calibration laboratories and instrument workshops for DMM/process instruments |
