Endress+Hauser
Endress+Hauser Turbimax CUS50D Turbidity Sensor
السعر عند الطلب
بدون دفع عبر الإنترنت · أضف بنودًا إلى قائمة طلب العرض
تنزيل ورقة المواصفات PDF
طلب العرض يحمل بنود قائمة المواد فقط. أرسل لعرض هندسي.
المعاملات الرئيسية
Communication
Memosens digital to Liquiline CM44x
Measuring Principle
Light attenuation / absorption at 860 nm per ISO 7027
Formazine Range
40 to 4,000 FAU (specified); max 10,000 FAU
Solids Range
Kaolin 0–60 g/L; sludge / auto sludge 0–25 g/L (specified operating)
Absorption Range
0.000 to 5.000 AU or 0.000 to 10.000 OD (factory absorption calibration)
Optical Paths
Dual path lengths 5 mm and 10 mm; glass-free PCTFE sensor head
| المعامل | القيمة |
|---|---|
| Communication | Memosens digital to Liquiline CM44x |
| Measuring Principle | Light attenuation / absorption at 860 nm per ISO 7027 |
| Formazine Range | 40 to 4,000 FAU (specified); max 10,000 FAU |
| Solids Range | Kaolin 0–60 g/L; sludge / auto sludge 0–25 g/L (specified operating) |
| Absorption Range | 0.000 to 5.000 AU or 0.000 to 10.000 OD (factory absorption calibration) |
| Optical Paths | Dual path lengths 5 mm and 10 mm; glass-free PCTFE sensor head |
| Process Temperature | −20 to 85 °C (−4 to 185 °F) |
| Process Pressure | 0.5 to 5 bar (7.3 to 73 psi) absolute (TI); product page also cites 0.5–4.5 bar class |
| Ingress Protection | IP68 |
| Materials | Sensor head PCTFE; shaft 1.4571 (316Ti) or PPS GF40; O-ring EPDM |
| Process Connections | G1 and NPT ¾; Clamp 2" option; air-cleaning option |
| Dimensions | 209.5 × 40 mm (8.25 × 1.57 in) class (product page) |
| Document | TI01395C/07/EN/06.25-00 (2025-10-20); BA01846CEN |
