E+E EE671 HVAC Air Velocity Probe

Compact hot-film air velocity probe for HVAC — selectable ranges to 20 m/s (4000 ft/min), voltage outputs 0–1 / 0–5 / 0–10 V or RS485 Modbus RTU, 10–29 V DC supply, M12 connector or fixed cable, alignment strip and mounting flange for correct immersion depth.

Key advantages

HVAC ranges — 0…5 / 10 / 15 / 20 m/s with published accuracies from ±(0.2 m/s + 3% mv).
Voltage or Modbus — 0–1/5/10 V (max 1 mA) or Modbus RTU.
Easy install — alignment strip + flange set immersion depth; M12 plug version available.
Contamination tolerant — thin-film element with transfer-molded probe head; probe IP54.
Configurable — PCS10 + optional adapter; Sigma 05 modular host compatible.

Typical applications

Heating and ventilation systems.
Flow monitoring and control in ducts.
Inlet air monitoring in ovens.
Sigma 05 modular sensor platform integrations.

Selection guide

Measuring range — 0…5 / 10 / 15 / 20 m/s order codes.
Output — 0–1 V, 0–5 V, 0–10 V (0–10 V needs supply ≥15 V), or Modbus RTU.
Connection — fixed cable or M12 plug.
Supply — 10–29 V DC SELV (Class III).
Environment — humidity 5…95 %RH non-condensing; probe IP54.

Common mistakes

Ordering 0–10 V output on a 12 V supply — OEM requires ≥15 V for 0–10 V.
Using EE671 for cleanroom laminar speeds below ~0.5 m/s accuracy band — consider EE660.
Skipping the alignment flange and mounting the probe off-axis in the duct.
Expecting IP65 enclosure rating — probe is IP54 per datasheet.

When to RFQ / what to tell us

Range and output (voltage vs Modbus).
M12 vs cable; any Sigma 05 host need.
Quantity and ship-to.
Duct size / mounting notes.

Request a Quote · Get selection help

Specs

Spec	Value
SKU	43252
Brand	E+E Elektronik
Model	EE671
Product type	HVAC air velocity probe
Measuring range	0…5 / 0…10 / 0…15 / 0…20 m/s
Accuracy	From ±(0.2 m/s + 3% of MV) on 0.5…5 m/s up to ±(0.4 m/s + 6% of MV) on 1…20 m/s
Outputs	0–1 / 0–5 / 0–10 V (max 1 mA) or Modbus RTU
Supply voltage	10–29 V DC SELV
Protection	Probe IP54
Notes	Specs from epluse.com EE671 product page and datasheet_EE671.pdf. Flange included in scope of supply.

Documents

FAQ

Q: Is a mounting flange included? A: Yes — OEM lists the mounting flange in the scope of supply for immersion-depth setting.

Q: Sigma 05 compatible? A: Yes — EE671 works with the E+E Sigma 05 modular sensor platform host.

Q: What should I send for a quote? A: Range, output, connector style, quantity, ship-to. Compatible with systems using E+E EE671 if you need a drop-in check — we do not claim authorized-dealer status.
