GF Signet 515 Rotor-X Paddlewheel Flow Sensor

Self-powered insertion paddlewheel (Rotor-X) for DN15…DN900 with sinusoidal frequency output proportional to velocity — no external sensor power required.

Key advantages

• Self-powered — sinusoidal frequency output; no external sensor supply.
• 0.3…6 m/s — turndown about 20:1; DN15…DN900 with GF Signet fittings.
• ±1% of max range linearity — repeatability ±0.5% of max range @ 25 °C.
• Material options — PP or PVDF body; multiple rotor/shaft/O-ring choices.

Typical applications

• Water, chemical, and utility lines using Signet fittings and frequency input transmitters/totalizers.
• Battery-powered totalizer loops (e.g. with compatible GF instruments).
• Simple insertion flow where open-collector powered sensors are not desired.

Selection guide

• Velocity / pipe — 0.3…6 m/s (1…20 ft/s); DN15…DN900 (½…36 in.).
• Electrical — ~19.7 Hz per m/s (~6 Hz per ft/s) sinusoidal; ~3.3 V p-p per m/s; source impedance ~8 kΩ.
• Cable — 2-conductor twisted shielded 22 AWG; 7.6 m (25 ft) standard; extendable to 60 m (200 ft).
• Wetted materials — Glass-filled PP or PVDF body; rotor PVDF/ETFE options; shaft Ti / Hastelloy-C / PVDF / ceramic / SS / Ta; O-rings FKM / EPDM / FFKM.
• Temperature / pressure — PP to 90 °C / 12.5 bar @ 20 °C; PVDF to 100 °C / 14 bar @ 20 °C (standard/integral ratings — confirm derate curves).

Common mistakes

• Expecting 4–20 mA directly from the sensor — 515 is self-powered frequency; pair with a compatible transmitter.
• Operating below 0.3 m/s — published range starts at 0.3 m/s (use 2537 family for lower velocity).
• Mismatching shaft/rotor materials to chemistry.
• Extending cable beyond 60 m without OEM guidance.
• Flow instruments · Flow buying guide

When to RFQ / what to tell us

1. Pipe size, fluid, velocity/flow.
2. Body (PP/PVDF), shaft/rotor, O-ring.
3. Host instrument / frequency input type; cable length; T/P; quantity; ship-to.

Request a Quote · Get selection help

Specs

Documents

• GF Signet 515 Rotor-X datasheet (PDF)

FAQ

Q: Does the 515 need DC power? A: No — it is self-powered. The host must accept its sinusoidal frequency signal.

Q: 515 vs 2537? A: 515 is classic self-powered Rotor-X from 0.3 m/s; 2537 adds low-flow to 0.1 m/s and powered S3L/4–20 mA options.

Q: What should I send for a quote? A: Pipe size, fluid, velocity, materials, host, T/P, quantity. Compatible with systems using GF Signet 515 if you need a drop-in check — we do not claim authorized-dealer status.
