Dwyer Instruments
Dwyer CSE-N1 Series Enclosures
Quote on request
No online payment · add lines to RFQ BOM
Dwyer CSE-N1: NEMA 1 carbon steel; 180° hinges; quarter-turn latch; wall mount. RFQ.
Download datasheet PDF
RFQ cart holds BOM lines only. Submit for engineering quote.
Key parameters
Approvals
CSA; cULus; RoHS II EU 2011/65/EU
Mounting
Wall mount; mounting holes on back; standoffs for optional sub-panels
Enclosure Rating
NEMA 1
Materials
Carbon steel
Thickness
0.060 in (1.52 mm) for enclosures <24 in wide; 0.075 in (1.91 mm) for ≥24 in wide; perforated sub-panels 0.060 in; solid sub-panels 0.075 in; mounting straps 0.078 in
Hinges
Butt hinges allowing 180° door rotation (2–3 hinges by size)
Fits indoor carbon-steel housings where you need a Dwyer CSE-N1 Series. NEMA 1 wall-mount enclosure in carbon steel with thickness 0.060/0.075 in by width class, butt hinges allowing 180° door rotation, screwdriver quarter-turn latch, rear mounting holes and standoffs for optional sub-panels.
Key advantages
- Rating — NEMA 1
- Material — Carbon steel
- Thickness — 0.060 / 0.075 in by width
- Door — 180° hinges; quarter-turn latch
- Mount — Wall; optional sub-panels
Typical applications
- Indoor instrument enclosures.
- Panel accessories.
- General NEMA 1 boxes.
Selection guide
- Size
- Sub-panel option
- Latch style
Common mistakes
- Outdoor exposure.
- Wrong size for DIN rail.
- No ground stud check.
When to RFQ / what to tell us
- Size/options.
- Quantity, ship-to.
Request a Quote · Get selection help
Specs
| Spec | Value |
|---|---|
| SKU | 47854 |
| Brand | Dwyer Instruments |
| Model | CSE-N1 Series |
| Product type | Enclosure |
| Enclosure rating | NEMA 1 |
| Materials | Carbon steel |
| Thickness | 0.060 in (1.52 mm) for enclosures <24 in wide; 0.075 in (1.91 mm) for ≥24 in wide; perforated sub-panels 0.060 in; solid sub-panels 0.075 in; mounting straps 0.078 in |
| Hinges | Butt hinges allowing 180° door rotation (2–3 hinges by size) |
| Latch | Quarter-turn latch opened/closed with screwdriver |
| Mounting | Wall mount; mounting holes on back; standoffs for optional sub-panels |
Documents
FAQ
Q: Rating? A: NEMA 1.
Q: Hinges? A: 180° butt hinges.
Q: What should I send for a quote? A: Size/options, quantity, ship-to.
Links
| Parameter | Value |
|---|---|
| Approvals | CSA; cULus; RoHS II EU 2011/65/EU |
| Mounting | Wall mount; mounting holes on back; standoffs for optional sub-panels |
| Enclosure Rating | NEMA 1 |
| Materials | Carbon steel |
| Thickness | 0.060 in (1.52 mm) for enclosures <24 in wide; 0.075 in (1.91 mm) for ≥24 in wide; perforated sub-panels 0.060 in; solid sub-panels 0.075 in; mounting straps 0.078 in |
| Hinges | Butt hinges allowing 180° door rotation (2–3 hinges by size) |
| Latch | Quarter-turn latch opened/closed with screwdriver |
| Size Range | Model chart from CSE-N1-100804 (10×8×4 in) through larger sizes e.g. CSE-N1-303008 (30×30×8 in) |
| Weight Range | Approx. 5 to 60+ lb depending on model (see chart) |
| Knockouts | CSE-N1 without knockouts; related CSE-KN series includes knockouts |
| Applications | HVAC indoor; housing general controls and gages; securing instrumentation |
