Mensor (WIKA)
Mensor CPG2300 Digital Pressure Gauge
Quote on request
No online payment · add lines to RFQ BOM
Mensor CPG2300: dual channel; A to 6000 psig; B to 1000 psi; RS-232. RFQ.
Download datasheet PDF
RFQ cart holds BOM lines only. Submit for engineering quote.
Key parameters
Accuracy
0.015% FS
Display
Monochrome 128×64 LCD with white LED backlight
Instrument Type
Portable dual-sensor digital pressure gauge / field calibrator
Pressure Ranges
Channel A to 6,015 psi; Channel B 5–1,000 psig or 7.5–1,000 psia
Temperature Compensation
Dynamic 0 to 50 °C
Sensors
One or two independent precision pressure sensors; absolute/gauge/bi-directional/vacuum
Fits precision dual-channel pressure indication where you need a Mensor CPG2300—Channel A up to about 6,000 psig and Channel B up to about 1,000 psig/psia with RS-232 output.
Key advantages
- Channel A — Up to about 6,000 psig
- Channel B — Up to about 1,000 psig/psia
- Comms — RS-232
- Type — Dual-channel digital pressure gauge
- Platform — Mensor CPG2300
Typical applications
- Bench dual-range indication.
- Calibration reference readout.
- Lab pressure monitoring.
Selection guide
- Channel ranges
- Absolute vs gauge on B
- Cable / software
Common mistakes
- Overranging a channel.
- Wrong media.
- Ignoring warm-up.
When to RFQ / what to tell us
- Channel ranges.
- Quantity, ship-to.
Request a Quote · Get selection help
Specs
| Spec | Value |
|---|---|
| SKU | 40270 |
| Brand | Mensor |
| Model | CPG2300 |
| Product type | Digital Pressure Gauge |
| Type | Dual-channel digital pressure gauge (CPG2300) |
| Range | Channel A up to 6,000 psig; channel B up to 1,000 psig/psia |
| Output | RS-232 |
| Feature | Precision digital pressure indication |
Documents
FAQ
Q: Max on A? A: About 6,000 psig.
Q: Comms? A: RS-232.
Q: What should I send for a quote? A: Ranges/quantity, ship-to.
Links
| Parameter | Value |
|---|---|
| Accuracy | 0.015% FS |
| Display | Monochrome 128×64 LCD with white LED backlight |
| Instrument Type | Portable dual-sensor digital pressure gauge / field calibrator |
| Pressure Ranges | Channel A to 6,015 psi; Channel B 5–1,000 psig or 7.5–1,000 psia |
| Temperature Compensation | Dynamic 0 to 50 °C |
| Sensors | One or two independent precision pressure sensors; absolute/gauge/bi-directional/vacuum |
| Loop Power | Analog mA measurement channel; can power control loop |
| Functions | Min/max peak, rate, null; dual-channel simultaneous display |
| Pressure Units | 17 selectable + 1 user-defined |
| Applications | Field transmitter calibration, clean rooms, utilities, pharma |
| Datasheet | WIKA CPG2300 |
| Warranty | Two year warranty (OEM) |
