Optris
Optris PI 1M Infrared Camera
Quote on request
No online payment · add lines to RFQ BOM
Optris PI 1M: short-wave IR camera; 450…1800 °C; to 1 kHz; USB/GigE. RFQ.
Download datasheet PDF
RFQ cart holds BOM lines only. Submit for engineering quote.
Key parameters
Accuracy
±1 % of reading (<1400 °C, 27/32/80 Hz); ±2 % (<1600 °C)
Ambient temperature
5…50 °C
Temperature Ranges
450…1800 °C (27 Hz); 500…1800 °C (80/32 Hz); 600…1800 °C (1 kHz)
Optical Resolution
764×480 @ 32 Hz; 382×288 @ 80 Hz; 72×56 / 764×8 @ 1 kHz
Detector
CMOS 15 µm × 15 µm
Spectral Range
0.85 – 1.1 µm
Fits high-temperature metal imaging where you need an Optris PI 1M—short-wave IR camera (0.85–1.1 µm) with ranges from about 450…1800 °C, frame modes to 1 kHz, NETD under 2–4 K by temperature, and USB 2.0 with optional GigE.
Key advantages
- Spectral — 0.85–1.1 µm CMOS
- Temp — About 450…1800 °C by mode
- Speed — Modes to 1 kHz
- Accuracy — ±1% of reading class (<1400 °C)
- Enclosure — IP67; about 245–311 g
Typical applications
- Hot metal process imaging.
- Laser / welding monitoring.
- High-temp R&D.
Selection guide
- Frame mode vs resolution
- Lens
- GigE option
Common mistakes
- Wrong spectral for low-temp.
- Missing cooling/ambient care.
- Undersized FOV.
When to RFQ / what to tell us
- Lens/mode/options.
- Quantity, ship-to.
Request a Quote · Get selection help
Specs
| Spec | Value |
|---|---|
| SKU | 44939 |
| Brand | Optris |
| Model | PI 1M |
| Product type | Infrared Camera |
| Temperature ranges | 450…1800 °C (27 Hz); 500…1800 °C (80/32 Hz); 600…1800 °C (1 kHz) |
| Optical resolution | 764×480 @ 32 Hz; 382×288 @ 80 Hz; 72×56 / 764×8 @ 1 kHz |
| Detector | CMOS 15 µm × 15 µm |
| Spectral range | 0.85 – 1.1 µm |
| NETD | <2 K (<900 °C); <4 K (<1400 °C) |
| Accuracy | ±1 % of reading (<1400 °C, 27/32/80 Hz); ±2 % (<1600 °C) |
| PC interface | USB 2.0; optional USB to GigE (PoE) |
| Enclosure | 46 × 56 × 88–129 mm / IP67 (NEMA 4) |
Documents
FAQ
Q: Spectral? A: 0.85–1.1 µm.
Q: Max rate? A: Up to 1 kHz modes.
Q: What should I send for a quote? A: Lens/mode/options, quantity, ship-to.
Links
| Parameter | Value |
|---|---|
| Accuracy | ±1 % of reading (<1400 °C, 27/32/80 Hz); ±2 % (<1600 °C) |
| Ambient temperature | 5…50 °C |
| Temperature Ranges | 450…1800 °C (27 Hz); 500…1800 °C (80/32 Hz); 600…1800 °C (1 kHz) |
| Optical Resolution | 764×480 @ 32 Hz; 382×288 @ 80 Hz; 72×56 / 764×8 @ 1 kHz |
| Detector | CMOS 15 µm × 15 µm |
| Spectral Range | 0.85 – 1.1 µm |
| Netd | <2 K (<900 °C); <4 K (<1400 °C) |
| Pc Interface | USB 2.0; optional USB to GigE (PoE) |
| Analog Output | 1 ms real-time 0–10 V of selectable 8×8 pixels (1 kHz mode) |
| Enclosure | 46 × 56 × 88–129 mm / IP67 (NEMA 4) |
| Weight | 245–311 g depending on lens |
| Power Supply | via USB |
