ABB ScreenMaster SM500F Field-Mount Paperless Recorder
ABB ScreenMaster SM500F Field-Mount: Wall / pipe / panel; ~90 mm deep; Up to 8 software recording channels; Up to 4 universal (+ expansion). RFQ.
RFQ cart holds BOM lines only. Submit for engineering quote.
Key parameters
Fits field-mount paperless recording where you need an ABB ScreenMaster SM500F. Wall/pipe/panel enclosure ~90 mm deep, up to 8 software recording channels, up to 4 universal inputs (TC, RTD 3/4-wire, mA, resistance, digital) with optional expansion, internal Flash + SD archive, Ethernet with webserver/FTP/email/Modbus TCP, NEMA 4X / IP66, color TFT or monochrome display, up to 32 process alarms plus totalizers/math/logic.
Key advantages
- Mount — Wall / pipe / panel; ~90 mm deep
- Channels — Up to 8 software recording channels
- Inputs — Up to 4 universal (+ expansion)
- Comms — Ethernet webserver/FTP/email/Modbus TCP
- Protection — NEMA 4X / IP66 field enclosure
Typical applications
- Harsh-field process recording.
- Remote Ethernet recorder access.
- Multi-channel paperless panels.
Selection guide
- Input count / expansion
- Color vs mono display
- Alarm / totalizer / math needs
Common mistakes
- Under-counting software channels vs physical inputs.
- Ignoring SD archive policy.
- Wrong mount kit for pipe vs wall.
When to RFQ / what to tell us
- Inputs, display, options, mount, quantity, ship-to.
Request a Quote · Get selection help
Specs
| Spec | Value |
|---|---|
| SKU | 33330 |
| Brand | ABB |
| Model | ScreenMaster SM500F Field-Mount Paperless Recorder |
| Product type | Paperless Recorder |
| Type | ABB ScreenMaster SM500F field-mountable paperless / videographic process recorder |
| Mounting | Universal wall-, pipe- or panel-mount enclosure; ultra-slim depth about 90 mm (3.5 in) |
| Recording channels | Up to 8 software recording channels for analog/digital inputs, math results and Modbus TCP signals |
| Inputs | Up to 4 universal inputs (thermocouple, RTD 3/4-wire, mA, resistance, digital) with optional expansion |
| Memory | Internal Flash logging with archiving to removable SD memory card |
| Communications | Ethernet with webserver, FTP, email and Modbus TCP for remote access |
| Protection | NEMA 4X / IP66 field enclosure for harsh process environments |
| Display | Color TFT or monochrome display options with chart, bargraph and digital views |
| Alarms/totalizers | Up to 32 process alarms, 4 real-time alarms and multiple totalizers; math and logic equations |
Documents
FAQ
Q: Protection? A: NEMA 4X / IP66.
Q: Recording channels? A: Up to 8 software channels.
Q: What should I send for a quote? A: Inputs/display/options/mount, qty, ship-to.
Links
| Parameter | Value |
|---|---|
| Display | Color TFT or monochrome display options with chart, bargraph and digital views |
| Mounting | Universal wall-, pipe- or panel-mount enclosure; ultra-slim depth about 90 mm (3.5 in) |
| Type | ABB ScreenMaster SM500F field-mountable paperless / videographic process recorder |
| Recording Channels | Up to 8 software recording channels for analog/digital inputs, math results and Modbus TCP signals |
| Inputs | Up to 4 universal inputs (thermocouple, RTD 3/4-wire, mA, resistance, digital) with optional expansion |
| Memory | Internal Flash logging with archiving to removable SD memory card |
| Communications | Ethernet with webserver, FTP, email and Modbus TCP for remote access |
| Protection | NEMA 4X / IP66 field enclosure for harsh process environments |
| Alarms Totalizers | Up to 32 process alarms, 4 real-time alarms and multiple totalizers; math and logic equations |
| Document | ABB SM500F Field Mountable Videographic Recorder data sheet SS/SM500F Issue 4 (library.e.abb.com) |
