Rosemount
Rosemount 214A RTD and Thermocouple Temperature Sensor
Cotización a solicitud
Sin pago en línea · líneas en BOM RFQ
Descargar datasheet PDF
RFQ solo líneas BOM. Envíe para cotización de ingeniería.
Parámetros clave
Measuring range
RTD −196 to 600 °C (−321 to 1112 °F); thermocouple −40 to 1200 °C (−40 to 2192 °F) depending on type
Accuracy
RTD Class AA / A / B / 1/5 DIN B options; thermocouple Class 1 / Class 2
Output
Passive RTD or thermocouple EMF; for use with Rosemount transmitters
Process connection
Threaded, flanged, weld-pad, and sanitary options per model code
Ambient temperature
Application-dependent; limited by insulation, head, and approval class
Approvals
Hazardous-location approvals available per ordering table (ATEX/IECEx/FM/CSA options)
| Parámetro | Valor |
|---|---|
| Measuring range | RTD −196 to 600 °C (−321 to 1112 °F); thermocouple −40 to 1200 °C (−40 to 2192 °F) depending on type |
| Accuracy | RTD Class AA / A / B / 1/5 DIN B options; thermocouple Class 1 / Class 2 |
| Output | Passive RTD or thermocouple EMF; for use with Rosemount transmitters |
| Process connection | Threaded, flanged, weld-pad, and sanitary options per model code |
| Ambient temperature | Application-dependent; limited by insulation, head, and approval class |
| Approvals | Hazardous-location approvals available per ordering table (ATEX/IECEx/FM/CSA options) |
| Sensor type | PT100 / PT1000 RTD and multiple thermocouple types (built-to-order) |
| Sheath | Configurable sheath diameter and material; spring-loaded and direct-mount styles |
| Calibration | Callendar-Van Dusen constants and sensor matching available |
| Special Features | Built-to-order 214A family; RTD and thermocouple; connection-head and remote-mount configurations |
| Document | Product Data Sheet 00813-0600-2654 |
