Watlow
Watlow Style RB Industrial RTD
Cotización a solicitud
Sin pago en línea · líneas en BOM RFQ
Descargar datasheet PDF
RFQ solo líneas BOM. Envíe para cotización de ingeniería.
Parámetros clave
Measuring range
−50 to 260 °C (−58 to 500 °F) for Style RB rigid sheath construction
Accuracy
DIN/IEC 60751 Class A or Class B element options (typical Watlow RTD offering on RICRTD sheet)
Output
Passive RTD resistance (no transmitter in base Style RB)
Process connection
Plain sheath; use with fittings/thermowells as required by application
Approvals
Built to industrial RTD practice per Watlow RICRTD specification sheet
Sensor type
Style RB standard industrial RTD with insulated leads, internal heat-transfer plate, epoxy potting
| Parámetro | Valor |
|---|---|
| Measuring range | −50 to 260 °C (−58 to 500 °F) for Style RB rigid sheath construction |
| Accuracy | DIN/IEC 60751 Class A or Class B element options (typical Watlow RTD offering on RICRTD sheet) |
| Output | Passive RTD resistance (no transmitter in base Style RB) |
| Process connection | Plain sheath; use with fittings/thermowells as required by application |
| Approvals | Built to industrial RTD practice per Watlow RICRTD specification sheet |
| Sensor type | Style RB standard industrial RTD with insulated leads, internal heat-transfer plate, epoxy potting |
| Notes | Specs from Watlow Resistance Temperature Detectors specification sheet RICRTD0719 (Style RB section). Family sheet also covers RF/RC/RW styles. |
| Element Resistance | 100 Ω or 1000 Ω Pt elements (2-, 3-, or 4-wire) |
| Sheath Material | 316 stainless steel rigid sheath |
| Sheath Diameter | 0.125 to 0.250 in typical industrial diameters on family sheet |
| Lead Wire | Standard insulated leads; epoxy sealed to resist moisture pull-out; lead lengths configurable (up to long runs per catalog) |
| Insulation Resistance | Exceeds DIN-IEC-751 standards per Watlow RTD family claims |
