Endress+Hauser
Endress+Hauser Proline t-mass A 150 Thermal Mass Flow Meter
Cotización a solicitud
Sin pago en línea · líneas en BOM RFQ
Descargar datasheet PDF
RFQ solo líneas BOM. Envíe para cotización de ingeniería.
Parámetros clave
Measuring range
0.5 to 910 kg/h (1.1 to 2002 lb/h); up to 0.5–1365 kg/h (1.1–3003 lb/h) for air depending on ordering feature
Accuracy
3% o.r. / 4% o.r. / 5% o.f.s. depending on chosen ordering feature option
Output
4–20 mA HART, pulse/frequency/switch; compact DC 24 V transmitter
Wetted parts
Transducer / insertion tube / measuring tube 1.4404 (316L)
Protection
Compact robust transmitter; IP per TI environment section
Ambient temperature
Transmitter −40 to +60 °C (−40 to +140 °F)
| Parámetro | Valor |
|---|---|
| Measuring range | 0.5 to 910 kg/h (1.1 to 2002 lb/h); up to 0.5–1365 kg/h (1.1–3003 lb/h) for air depending on ordering feature |
| Accuracy | 3% o.r. / 4% o.r. / 5% o.f.s. depending on chosen ordering feature option |
| Output | 4–20 mA HART, pulse/frequency/switch; compact DC 24 V transmitter |
| Wetted parts | Transducer / insertion tube / measuring tube 1.4404 (316L) |
| Protection | Compact robust transmitter; IP per TI environment section |
| Ambient temperature | Transmitter −40 to +60 °C (−40 to +140 °F) |
| Measuring Principle | Thermal mass flow for utility gases (inline) |
| Line Size | Inline DN 15 to 50 (½ to 2 in) |
| Medium Temperature | Sensor −40 to +100 °C (−40 to +212 °F) typical; alternate seal ratings −10/−29 °C low ends |
| Medium Pressure | Max PN 40 / Class 300 |
| Special Features | Guided commissioning menus; self-diagnostics; multivariable trending |
