Endress+Hauser
Endress+Hauser Proline t-mass I 500 Thermal Mass Flow Meter
Cotización a solicitud
Sin pago en línea · líneas en BOM RFQ
Descargar datasheet PDF
RFQ solo líneas BOM. Envíe para cotización de ingeniería.
Parámetros clave
Measuring range
20 to 733501 kg/h (44 to 1669340 lb/h) gas/size dependent
Accuracy
Gas ±1.0% o.r. (10–100% o.f.s.); ±0.1% o.f.s. (1–10% o.f.s.)
Output
Remote Proline 500 transmitter; up to 4 I/Os; HART / Modbus RS485 and other fieldbuses
Wetted parts
Insertion tube stainless 1.4404 (316/316L); process connections G/NPT compression fittings
Protection
IP66/67 Type 4X; optional IP68 Type 6P (Proline 500)
Ambient temperature
−40 to +60 °C (−40 to +140 °F); optional colder ratings
| Parámetro | Valor |
|---|---|
| Measuring range | 20 to 733501 kg/h (44 to 1669340 lb/h) gas/size dependent |
| Accuracy | Gas ±1.0% o.r. (10–100% o.f.s.); ±0.1% o.f.s. (1–10% o.f.s.) |
| Output | Remote Proline 500 transmitter; up to 4 I/Os; HART / Modbus RS485 and other fieldbuses |
| Wetted parts | Insertion tube stainless 1.4404 (316/316L); process connections G/NPT compression fittings |
| Protection | IP66/67 Type 4X; optional IP68 Type 6P (Proline 500) |
| Ambient temperature | −40 to +60 °C (−40 to +140 °F); optional colder ratings |
| Display | Backlit touch control with WLAN access |
| Measuring Principle | Thermal mass insertion sensor for gases/mixtures in pipes or ducts; Gas Engine |
| Line Size | Insertion DN 80 to 1500 (3 to 60 in) |
| Bidirectional | Yes with reverse-flow detection options |
| Medium Temperature | Sensor −40 to +180 °C (−40 to +356 °F); FKM / 1.4404 seal options same range |
| Medium Pressure | −0.5 to 20 bar_g (−7.25 to 290 psi_g); max extraction pressure 16 bar typical |
| Special Features | Heartbeat Technology; SIL 2 sensor option; remote transmitter architecture |
