Yokogawa PROPLUS YPP6200 / YPP6300 Flow Rate/Totalizer

SKU · 36954 · PROPLUS YPP6200/YPP6300 · Marca: Yokogawa

Disponible

Cotización a solicitud

Sin pago en línea · líneas en BOM RFQ

Cantidad

RFQ solo líneas BOM. Envíe para cotización de ingeniería.

Parámetros clave

Measuring range

YPP6200: 0–20 mA, 4–20 mA, 0–5 V, 1–5 V, ±10 V; YPP6300: pulse/open-collector/NPN/PNP/TTL/switch-contact/sine/square

Output

Optional 2 or 4 SPDT relays; isolated 4–20 mA for rate or total

Supply

85–265 VAC / 90–265 VDC or 12–24 VDC / 12–24 VAC

Housing

1/8 DIN panel meter; NEMA 4X / IP65 front

Ambient temperature

Operating −40 to 65 °C (−40 to 149 °F)

Display

Dual-line 6-digit, 0.60 in / 0.46 in; standard or SunBright outdoor models

Parámetro	Valor
Measuring range	YPP6200: 0–20 mA, 4–20 mA, 0–5 V, 1–5 V, ±10 V; YPP6300: pulse/open-collector/NPN/PNP/TTL/switch-contact/sine/square
Output	Optional 2 or 4 SPDT relays; isolated 4–20 mA for rate or total
Supply	85–265 VAC / 90–265 VDC or 12–24 VDC / 12–24 VAC
Housing	1/8 DIN panel meter; NEMA 4X / IP65 front
Ambient temperature	Operating −40 to 65 °C (−40 to 149 °F)
Display	Dual-line 6-digit, 0.60 in / 0.46 in; standard or SunBright outdoor models
Communication	USB PROPLUS software; optional RS-232 / RS-485 Modbus RTU
Approvals	UL & C-UL Listed E348677; 508 Industrial Control Equipment
Mounting	1/8 DIN panel mount; optional NEMA 4X multi-meter enclosures
Functions	Simultaneous rate and total; grand total / non-resettable grand total; low-flow cutoff; square-root extraction; 32-point linearization; open-channel exponent
Transmitter Power	Isolated 24 VDC @ 200 mA (analog); 5/10/24 VDC flowmeter power (pulse)
