Optris CTlaser 1M / 2M Infrared Temperature Sensor

SKU · 45093 · CTlaser 1M / 2M · Бренд: Optris

В наличии

Цена по запросу

Без онлайн-оплаты · строки в RFQ BOM

Кол-во

RFQ только BOM. Отправьте для инженерного КП.

Ключевые параметры

Temperature Ranges

1ML 485…1050 °C; 1MH 650…1800 °C; 1MH1 800…2200 °C; 2ML 250…800 °C; 2MH 385…1600 °C; 2MH1 490…2000 °C

Spectral Ranges

1.0 μm (CTlaser 1M) / 1.6 μm (CTlaser 2M)

Optical Resolution

150:1 (1ML/2ML); 300:1 (1MH/1MH1/2MH/2MH1)

System Accuracy

±(0.3% of reading + 2 °C) at 23±5 °C (ε=1, 1 s)

Repeatability

±(0.1% of reading + 1 °C)

Exposure Time

1 ms (90%)

Параметр	Значение
Temperature Ranges	1ML 485…1050 °C; 1MH 650…1800 °C; 1MH1 800…2200 °C; 2ML 250…800 °C; 2MH 385…1600 °C; 2MH1 490…2000 °C
Spectral Ranges	1.0 μm (CTlaser 1M) / 1.6 μm (CTlaser 2M)
Optical Resolution	150:1 (1ML/2ML); 300:1 (1MH/1MH1/2MH/2MH1)
System Accuracy	±(0.3% of reading + 2 °C) at 23±5 °C (ε=1, 1 s)
Repeatability	±(0.1% of reading + 1 °C)
Exposure Time	1 ms (90%)
Aiming	Double laser aiming marks real spot location at any distance (635 nm, 1 mW)
Outputs	0/4–20 mA, 0–5/10 V, thermocouple J/K; optional digital (USB/RS485/Ethernet/…)
Power	8–36 V DC
Ambient	Sensing head/electronics −20…85 °C (laser ON limit 50 °C); IP65
Weight	Sensing head ~600 g; electronics ~420 g
Software	optris Compact Connect
Application	Metals, secondary metal processing, ceramics high-temp non-contact measurement
