Bently Nevada / TMS Model 9100D Portable Vibration Calibrator

SKU · 43971 · Model 9100D Shaker Table · Бренд: Bently Nevada

В наличии

Цена по запросу

Без онлайн-оплаты · строки в RFQ BOM

Кол-во

RFQ только BOM. Отправьте для инженерного КП.

Ключевые параметры

Frequency Range

5 Hz to 10 kHz (100 g payload; 300–600 k CPM)

Max Amplitude 10g Payload

20 g pk / 196 m/s² pk; 20 in/s pk; 500 mm/s pk; 150 mils pk-pk @ 50 Hz

Max Amplitude 500g Payload

2.5 g pk / 24.5 m/s² pk; 3.5 in/s pk; 90 mm/s pk @ 50 Hz

Maximum Payload

800 g (operating range reduced at higher payloads)

Sensor Mount

1/4-28 thread mounting platform

Test Operation

Manual (closed loop) or semi-automatic; auto-payload via reference accelerometer

Параметр	Значение
Frequency Range	5 Hz to 10 kHz (100 g payload; 300–600 k CPM)
Max Amplitude 10g Payload	20 g pk / 196 m/s² pk; 20 in/s pk; 500 mm/s pk; 150 mils pk-pk @ 50 Hz
Max Amplitude 500g Payload	2.5 g pk / 24.5 m/s² pk; 3.5 in/s pk; 90 mm/s pk @ 50 Hz
Maximum Payload	800 g (operating range reduced at higher payloads)
Sensor Mount	1/4-28 thread mounting platform
Test Operation	Manual (closed loop) or semi-automatic; auto-payload via reference accelerometer
Memory	500 calibration records; 30 data points per record; model/serial/orientation/notes
Readout Accuracy Amplitude	<1% up to 10 g pk (per datasheet accuracy of readout)
Dimensions	8.5 × 12 × 10 in (22 × 30.5 × 28 cm)
Weight	18 lb (8.2 kg)
Operating Temperature	32 to 122°F (0 to 50°C)
Battery	12 Vdc 4 Ah sealed gel lead-acid; ~18 h @ 100 Hz / 1 g pk / 100 g payload (new)
Reference	Built-in NIST-traceable reference accelerometer permanently attached to armature
Programmability	Up to 30 test points per routine with Pass/Fail bounds
