Panametrics
Panametrics PanaFlow MV82 Flow Meter
Цена по запросу
Без онлайн-оплаты · строки в RFQ BOM
Скачать datasheet PDF
RFQ только BOM. Отправьте для инженерного КП.
Ключевые параметры
Process connection
2 in male NPT or 2 in 150/300/600 lb flanges (style-dependent)
Wetted parts
316L stainless steel; PTFE or graphite packing options
Ambient temperature
Operating –5 to 185 °F; storage –40 to 185 °F
Meter Style
Insertion multivariable vortex (velocity + RTD + pressure transducer options)
Fluid Types
Steam, gases, and liquids
Accuracy Volumetric
Liquids ±1.2% of rate; gas and steam ±1.5% of rate
| Параметр | Значение |
|---|---|
| Process connection | 2 in male NPT or 2 in 150/300/600 lb flanges (style-dependent) |
| Wetted parts | 316L stainless steel; PTFE or graphite packing options |
| Ambient temperature | Operating –5 to 185 °F; storage –40 to 185 °F |
| Meter Style | Insertion multivariable vortex (velocity + RTD + pressure transducer options) |
| Fluid Types | Steam, gases, and liquids |
| Accuracy Volumetric | Liquids ±1.2% of rate; gas and steam ±1.5% of rate |
| Accuracy Mass | Liquids ±1.5% of rate; gas and steam ±2% of rate (50–100% of pressure range) |
| Accuracy Temperature | ±2 °F (±1 °C) |
| Accuracy Pressure | ±0.3% of full scale |
| Repeatability Mass | ±0.2% of rate |
| Process Temperature | Standard –40 to 500 °F (–40 to 260 °C); high-temp up to 750 °F (400 °C) |
| Outputs | Up to three 4–20 mA; alarms; totalizer pulse; HART, Modbus, BACnet |
| Enclosure Rating | Type 4X and IP66; explosion-proof Class I Div 1; ATEX/IECEx Ex d |
| Turndown | Application-dependent; can exceed 100:1 |
| Response Time | Adjustable 1 to 100 seconds |
