ICON Process Controls
ICON Process Controls IZON LRT Series Long Range (LoRa) Wireless Transmitter
SKU · 140923 · IZON LRT Series Long Range (LoRa) Wireless Transmitter · Бренд: ICON Process Controls
Цена по запросу
Без онлайн-оплаты · строки в RFQ BOM
Скачать datasheet PDF
RFQ только BOM. Отправьте для инженерного КП.
Ключевые параметры
Type
IZON LRT Series LoRa long-range wireless transmitter / gateway (LRT-4000 class)
Protocol
LoRa wireless; AES 128/256 encryption
Frequency
915 MHz class (region-dependent)
Rf Power
Maximum 2 W transmit RF power class; range 10 mi+ LOS / 2 mi+ industrial class per datasheet
Interface
Analog 4-20 mA input; RS-485 (see manufacturer datasheet for availability)
Enclosure
IP68 / NEMA 4X outdoor/indoor
| Параметр | Значение |
|---|---|
| Type | IZON LRT Series LoRa long-range wireless transmitter / gateway (LRT-4000 class) |
| Protocol | LoRa wireless; AES 128/256 encryption |
| Frequency | 915 MHz class (region-dependent) |
| Rf Power | Maximum 2 W transmit RF power class; range 10 mi+ LOS / 2 mi+ industrial class per datasheet |
| Interface | Analog 4-20 mA input; RS-485 (see manufacturer datasheet for availability) |
| Enclosure | IP68 / NEMA 4X outdoor/indoor |
| Operating Temp | -40 C to 85 C |
| Power | 12-36 VDC / 1 A input; 5 VDC / 200 mA output supply |
| Dimensions Weight | Main unit about 10 x 10 x 4.8 cm; about 195 g |
| Connectors | M12 quick connect |
| Topology | Broadcast / Group / Peer-to-Peer |
| Document | ICON Process Controls IZON LRT Series transmitter data sheet 25-0629 |
